TIG780-52 Hot Sale 5.2W High Quality Thermal Grease Cpu Gpu Graphics Card Conductivity Transistor Thermal Silicone Paste
The TIG™780-52 is environmentally safe silicone-based thermal grease designed to solve overheating and reliability issue.
TIG™780-52 is presenting thermal paste products. They serve to moisten the contact surface sufficiently so as to form an interface of extremely low thermal impedance.Consequently, the heat dissipation efficiency is farsuperior to that offered by others.
Features
>Low thermal resistance
>Non-toxic and environmentally safe
>Excellent long term stability
>Thoroughly wets out contact surfaces to create low thermal resistance
Applications lnclude
>Display card
>Mainboard/mother board
>Notebook
>Power supply
>Heat pipe thermal solutions
>Memory Modules
>Mass storage devices
>Automotive electronics
>Set top boxes
>Cpu Gpu Graphics Card
| Typical Properties of TIG™780-52 Series |
| ProductName | TIG™780-52 | Test Method |
| Color | Gray | Visual |
| Construction &Compostion | Metal oxide filled silicone oil | ***** |
| Viscosity | 200K cps @ 25℃ | GB/T 10247 |
| Specific Gravity | 2.3 g/cm³ | ASTM D2240 |
| Continuous Use Temp | -45℃ to 200℃ | ***** |
| Bond line thickness(mm) | 0.008 | ASTM D374 |
| Thermal Conductivity | 5.2 W/mK | ASTM D5470 |
| Thermal lmpedance @ 50 psi | 0.012 (℃-in²/W ) | ASTM D5470 |
| Thermal lmpedance @ 30 psi | 0.015 (℃-in²/W ) | ASTM D5470 |
| Fire rating | 94 V-0 | UL |
Package
TIG™780-52 Series is available in 1kg (pint container), 3kg (quart container), and 10kg(gallon container).
Storage:
Store from 5°C to 25°C with a maximum humidity of 70%. Do not store in freezer or refrigerator below 10°C.
Company profile
With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.
Certifications:
ISO9001:2015
ISO14001: 2004 IATF16949:2016
IECQ QC 080000:2017
UL
FAQ:
Q: Are you trading company or manufacturer ?
A: We are manufacturer in Vietnam.
Q: How long is your delivery time?
A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.
Q: How to find a right thermal conductivity for my applications
A: It depends on the watts of power source , ability of heat dissipation. Please tell us your detailed applications and the power, so we can recommend most suitable thermal conductive materials.
|
|
